・Let’s Encrypt(certbot)の証明書更新がエラー「The Certificate Authority failed to verify the temporary Apache configuration changes made by Certbot」になるときの対処方法を知りたい。
・具体的な手順を教えてほしい。
こういった疑問に答えます。
本記事の内容
- Let’s Encrypt(certbot)の証明書更新がエラー「The Certificate Authority failed to verify the temporary Apache configuration changes made by Certbot」になるときの対処方法
この記事を書いている私は、某SIerに勤務しながら、
WEB系エンジニア・インフラエンジニアに憧れて、プログラミングおよびインフラ技術の勉強をしています。
こういった私が、解説していきます。
私が実機で試したコマンドや画像を載せて書いています。
記事の信頼性担保に繋がると思います。
Let’s Encrypt(certbot)の証明書更新がエラー「The Certificate Authority failed to verify the temporary Apache configuration changes made by Certbot」になるときの対処方法
発生事象
cronで定期的に証明書更新を実施していたのですが、ある日から突然、エラーが起きるようになりました。
エラーメッセージ
certbot renew --dry-run
[root@SV-ALTAIR ~]# certbot renew --dry-run Saving debug log to /var/log/letsencrypt/letsencrypt.log - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Processing /etc/letsencrypt/renewal/test01.sv-altair.●●●●●●●●●●●.conf - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Simulating renewal of an existing certificate for test01.sv-altair.●●●●●●●●●●● and www.test01.sv-altair.●●●●●●●●●●● Certbot failed to authenticate some domains (authenticator: apache). The Certificate Authority reported these problems: Domain: test01.sv-altair.●●●●●●●●●●● Type: connection Detail: XXX.XXX.XXX.XXX: Fetching http://test01.sv-altair.●●●●●●●●●●●/.well-known/acme-challenge/ZZZZZZZZZZZZZZZZZZZZZZZZZ: Error getting validation data Domain: www.test01.sv-altair.●●●●●●●●●●● Type: connection Detail: XXX.XXX.XXX.XXX: Fetching http://www.test01.sv-altair.●●●●●●●●●●●/.well-known/acme-challenge/ZZZZZZZZZZZZZZZZZZZZZZZZZ: Error getting validation data Hint: The Certificate Authority failed to verify the temporary Apache configuration changes made by Certbot. Ensure that the listed domains point to this Apache server and that it is accessible from the internet. Failed to renew certificate test01.sv-altair.●●●●●●●●●●● with error: Some challenges have failed. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - All simulated renewals failed. The following certificates could not be renewed: /etc/letsencrypt/live/test01.sv-altair.●●●●●●●●●●●/fullchain.pem (failure) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 renew failure(s), 0 parse failure(s) Ask for help or search for solutions at https://community.letsencrypt.org. See the logfile /var/log/letsencrypt/letsencrypt.log or re-run Certbot with -v for more details.
証明書更新のときに、
「/.well-known/acme-challenge/ZZZZZZZZZZZZZZZZZZZZZZZZZ」に
一時ファイルを作ろうとするがアクセスできずにエラーになっているようです。
The Certificate Authority failed to verify the temporary Apache configuration changes made by Certbot. Ensure that the listed domains point to this Apache server and that it is accessible from the internet.
原因の推測
該当のWEBサーバーは、ファイアウォールで日本国内からのアクセスしか許可しておらず、
これが原因かと推測し、一時的に、ファイアウォールでpublicゾーンにhttpサービスの許可を追加して、
エラーが解消するかを確認します。
[root@SV-ALTAIR ~]# firewall-cmd --zone=public --add-service=http success
[root@SV-ALTAIR ~]# certbot renew --dry-run Saving debug log to /var/log/letsencrypt/letsencrypt.log - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Processing /etc/letsencrypt/renewal/test01.sv-altair.●●●●●●●●●●●.conf - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Simulating renewal of an existing certificate for test01.sv-altair.●●●●●●●●●●● and www.test01.sv-altair.●●●●●●●●●●● - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - The following simulated renewals succeeded: /etc/letsencrypt/live/test01.sv-altair.●●●●●●●●●●●/fullchain.pem (success) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
ファイアウォールで許可を追加したら「success」になりました!
根本対応
常時、publicゾーンでhttpサービスを許可したくはないので、
ファイアウォールにcertbot用のゾーンを用意しています。
そこに、certbotの接続元IPアドレスを追加します。
[root@SV-ALTAIR ~]# firewall-cmd --zone=certbot --add-source=34.220.116.34/32 --permanent success [root@SV-ALTAIR ~]# firewall-cmd --reload success
certbot (active) target: ACCEPT icmp-block-inversion: no interfaces: sources: 23.178.112.202/32 23.178.112.204/32 34.222.79.253/32 52.13.142.142/32 3.15.188.211/32 18.189.13.130/32 23.178.112.106/32 23.178.112.107/32 34.220.116.34/32 18.191.28.4/32 66.133.109.36/32 services: http ports: protocols: forward: no masquerade: no forward-ports: source-ports: icmp-blocks: rich rules:
certbotの接続元IPアドレス
/var/log/httpd/test01.sv-altair.●●●●●●●●●●●-access_log
23.178.112.202 - - [07/Jan/2024:05:17:10 +0900] "GET /.well-known/acme-challenge/ZZZZZZZZZZZZZZZ HTTP/1.1" 200 87 "-" "Mozilla/5.0 (compatible; Let's Encrypt validation server; +https://www.letsencrypt.org)" 18.191.28.4 - - [07/Jan/2024:09:58:09 +0900] "GET /.well-known/acme-challenge/ZZZZZZZZZZZZZZZ HTTP/1.1" 200 87 "-" "Mozilla/5.0 (compatible; Let's Encrypt validation server; +https://www.letsencrypt.org)" 66.133.109.36 - - [07/Jan/2024:09:58:09 +0900] "GET /.well-known/acme-challenge/ZZZZZZZZZZZZZZZ HTTP/1.1" 200 87 "-" "Mozilla/5.0 (compatible; Let's Encrypt validation server; +https://www.letsencrypt.org)" 66.133.109.36 - - [07/Jan/2024:09:58:10 +0900] "GET /.well-known/acme-challenge/ZZZZZZZZZZZZZZZ HTTP/1.1" 200 87 "-" "Mozilla/5.0 (compatible; Let's Encrypt validation server; +https://www.letsencrypt.org)" 18.191.28.4 - - [07/Jan/2024:09:58:19 +0900] "GET /.well-known/acme-challenge/ZZZZZZZZZZZZZZZ HTTP/1.1" 200 87 "-" "Mozilla/5.0 (compatible; Let's Encrypt validation server; +https://www.letsencrypt.org)" 34.220.116.34 - - [07/Jan/2024:09:58:19 +0900] "GET /.well-known/acme-challenge/ZZZZZZZZZZZZZZZ HTTP/1.1" 200 87 "-" "Mozilla/5.0 (compatible; Let's Encrypt validation server; +https://www.letsencrypt.org)" 34.220.116.34 - - [07/Jan/2024:09:58:19 +0900] "GET /.well-known/acme-challenge/ZZZZZZZZZZZZZZZ HTTP/1.1" 200 87 "-" "Mozilla/5.0 (compatible; Let's Encrypt validation server; +https://www.letsencrypt.org)" 66.133.109.36 - - [07/Jan/2024:10:13:20 +0900] "GET /.well-known/acme-challenge/ZZZZZZZZZZZZZZZ HTTP/1.1" 200 87 "-" "Mozilla/5.0 (compatible; Let's Encrypt validation server; +https://www.letsencrypt.org)" 34.220.116.34 - - [07/Jan/2024:10:13:20 +0900] "GET /.well-known/acme-challenge/ZZZZZZZZZZZZZZZ HTTP/1.1" 200 87 "-" "Mozilla/5.0 (compatible; Let's Encrypt validation server; +https://www.letsencrypt.org)" 18.191.28.4 - - [07/Jan/2024:10:13:20 +0900] "GET /.well-known/acme-challenge/ZZZZZZZZZZZZZZZ HTTP/1.1" 200 87 "-" "Mozilla/5.0 (compatible; Let's Encrypt validation server; +https://www.letsencrypt.org)" 66.133.109.36 - - [07/Jan/2024:10:13:20 +0900] "GET /.well-known/acme-challenge/ZZZZZZZZZZZZZZZ HTTP/1.1" 200 87 "-" "Mozilla/5.0 (compatible; Let's Encrypt validation server; +https://www.letsencrypt.org)" 18.191.28.4 - - [07/Jan/2024:10:13:29 +0900] "GET /.well-known/acme-challenge/ZZZZZZZZZZZZZZZ HTTP/1.1" 200 87 "-" "Mozilla/5.0 (compatible; Let's Encrypt validation server; +https://www.letsencrypt.org)" 34.220.116.34 - - [07/Jan/2024:10:13:30 +0900] "GET /.well-known/acme-challenge/ZZZZZZZZZZZZZZZ HTTP/1.1" 200 87 "-" "Mozilla/5.0 (compatible; Let's Encrypt validation server; +https://www.letsencrypt.org)"
もともと2023年までに設定していたIPアドレス
23.178.112.202 23.178.112.204 34.222.79.253 52.13.142.142 3.15.188.211 18.189.13.130 23.178.112.106 23.178.112.107
2024年1月に追加したIPアドレス
34.220.116.34 18.191.28.4 66.133.109.36
